Gridlap Comb

Anchor divider strips to a drawer wall

The wall rail for Gridlap: a 200 mm comb with 2.4 mm slots on the same 30 mm pitch, stuck to the drawer side with foam tape. Strip ends drop into its teeth, so a grid holds square to the wall and T-junctions work without crossing strips.

Customize this model

Size: 200 × 200 × 40 mm
Shape: Custom outline
Walls: 5.0 mm
Volume: 657 cm³
Est. weight (PLA): 815 g
Parts to print: 1
Category: Drawer & cabinet organisers
Made by: Krypto
Built in: 4 steps

What’s in it

Custom outline, 200 × 200 × 40 mm, with 5.0 mm walls
Custom outline traced from a shape

How to print it

Print as it comes (comb on the bed), solid; fix with foam tape.

Filament: at most about 815 g of PLA printed solid (roughly $16.30 at $20 per kg); normal infill uses less.

To get the files, open it in the generator and choose File › Download STL (one file per part) or Download 3MF (every part on one plate).

Questions

What size is the gridlap Comb model?

The gridlap Comb model measures 200 × 200 × 40 mm (width × depth × height). You can change every size in the free SO3D.xyz generator before you download it.

Does it need supports?

Usually not. Print as it comes (comb on the bed), solid; fix with foam tape.

How much filament does it use?

At most about 815 g of PLA (657 cm³ printed solid), roughly $16.30 of filament at $20 per kg. Normal infill uses less.

Can I change it?

Yes. Open it in the SO3D.xyz generator (free, in your browser), change the size, walls, dividers, holes, text or anything else, then download it as STL or 3MF for your slicer.
