Stripboard track cutter handle

Cut copper tracks on stripboard

Push a 6 mm drill bit shank first into the socket and the handle turns it into a track cutter: set the point in a stripboard hole and twist, and the copper track is cut cleanly through without a drill or a craft knife lifting the copper.

Customize this model

Size (Base A): Ø 28 mm, 40 mm tall
Shape: Round
Walls: 2.4 mm
Volume: 12.4 cm³
Est. weight (PLA): 15.4 g
Parts to print: 1
Category: Electronics & robotics
Made by: Krypto
Built in: 15 steps

What’s in it

Round, Ø 28 mm, 40 mm tall, with 2.4 mm walls
2 more bases built on (Bases B–C)
Base B: round, Ø 28 mm (stacked)
Base C: round, Ø 14 mm, 25 mm tall (stacked)

How to print it

A drop of glue holds the bit for good.

Prints as shown on its floor, no supports. Stacked parts are fused into one print.

Filament: at most about 15.4 g of PLA printed solid (roughly $0.31 at $20 per kg); normal infill uses less.

To get the files, open it in the generator and choose File › Download STL (one file per part) or Download 3MF (every part on one plate).

Questions

What size is the stripboard track cutter handle model?

The stripboard track cutter handle model measures Ø 28 mm, 40 mm tall. That is Base A; 2 more bases are built on. You can change every size in the free SO3D.xyz generator before you download it.

Does it need supports?

No. A drop of glue holds the bit for good. Prints as shown on its floor, no supports. Stacked parts are fused into one print.

How much filament does it use?

At most about 15.4 g of PLA (12.4 cm³ printed solid), roughly $0.31 of filament at $20 per kg. Normal infill uses less.

Can I change it?

Yes. Open it in the SO3D.xyz generator (free, in your browser), change the size, walls, dividers, holes, text or anything else, then download it as STL or 3MF for your slicer.
