Check guitar string action
Measures string height at the 12th fret: slide the four steps, 1.5 to 3.0 mm, under the low and high E strings to see how high the action is before you adjust the bridge.
Print with 100% infill and check against calipers.
Prints as shown on its outline, no supports.
Filament: at most about 13.6 g of PLA printed solid (roughly $0.27 at $20 per kg); normal infill uses less.
To get the files, open it in the generator and choose File › Download STL (one file per part) or Download 3MF (every part on one plate).
The guitar string action gauge model measures 80 × 14 × 12 mm (width × depth × height). You can change every size in the free SO3D.xyz generator before you download it.
No. Print with 100% infill and check against calipers. Prints as shown on its outline, no supports.
At most about 13.6 g of PLA (11.0 cm³ printed solid), roughly $0.27 of filament at $20 per kg. Normal infill uses less.
Yes. Open it in the SO3D.xyz generator (free, in your browser), change the size, walls, dividers, holes, text or anything else, then download it as STL or 3MF for your slicer.
Change the size, walls, dividers, holes and labels of the guitar string action gauge model in your browser, then download it for your printer. Free, no CAD needed.
